Place of Origin:
Shenzhern,China
Brand Name:
RGH
Certification:
ISO9001/ISO14001
Model Number:
RT55HD011A
Document:
| NO. | Symbol | Level | Function |
| 1-2 | LEDA2 | LED anode | |
| 3-4 | LEDK2 | LED cathode | |
| 5-10 | NC | NC | |
| 11 | GND | Ground | |
| 12-13 | VDD | Power setting | |
| 14-15 | IOvCC | A supply voltage tothe digital circuit.Connect to an external power supplyof1.65~3.3V |
|
| 16 | GND | Ground | |
| 17 | RESET | Initialize the chip with a low input.Be sure toexecute a power-on reset after supplying power. |
|
| 18 | GND | Ground | |
| 19 | D3P | MIPI DSI differential data pair. | |
| 20 | D3N | MIPI DSI differential data pair. | |
| 21 | GND | Ground | |
| 22 | D2P | MIPI DSI differential data pair. | |
| 23 | D2N | MIPI DSI differential datapair. | |
| 24 | GND | Ground | |
| 25 | CLKP | MIPI DSI diffe rential clock pair. | |
| 26 | CLKN | MIPI DSI differential clockpair. | |
| 27 | GND | Ground | |
| 28 | D1P | MIPI DSI differential data pair. | |
| 29 | D1N | MIPIDSI differential data pair. | |
| 30 | GND | Ground | |
| 31 | D0P | MIPI DSI differential data pair. | |
| 32 | D0N | MIPIDSI differential data pair. | |
| 33-34 | GND | Ground | |
| 35 | TP-RST | TP-RST | |
| 36 | TP-INT | TP-INT | |
| 37 | TP-SDA | TP-SDA | |
| 38 | TP-SCL | TP-SCL | |
| 39 | TP-GND | TP-GND | |
| 40 | TP-VDD | TP-VDD |
|
|
