Place of Origin:
Shenzhern,China
Brand Name:
RGH
Certification:
ISO9001/ISO14001
Model Number:
RT31WV002A
Document:
| Item | Specification |
|---|---|
|
Size |
3.1inch |
|
Display mode |
Transmissive TFT
|
|
Part NO. |
RT31WV002A
|
|
Resolution |
480X800 |
|
Outline size |
43.48(W) X74.72(H) X1.68(T
|
|
Active area |
40.32(W) X67.20(H)
|
|
View direction |
ALL o’clock
|
|
Piexl pitch |
480(RGB)X800
|
|
Interface |
MIPI |
|
Backlight |
6LEDS |
|
Surface luminance |
450cd/m2 |
|
Logic voltage |
2.5V-3.3V |
|
Operating temperature |
-20℃~70℃
|
|
Storage temperature |
-30℃~80℃
|
| NO. | Symbol | Level | Function |
| 1 | GND | Ground pin for analog circuits | |
| 2 | DN0 | Mipi data signal | |
| 3 | DP0 | Mipi data signal | |
| 4 | GND | Ground pin for analog circuits | |
| 5 | CKN | Mipi clock signal | |
| 6 | CKP | Mipi clock signal | |
| 7 | GND | ||
| 8 | DN1 | Mipi data signa | |
| 9 | DP1 | Mipi data signal | |
| 10 | GND | Ground pin for analog circuits | |
| 11 | RESET | System reset pin | |
| 12 | IOvCC | 1.8V | Power setting |
| 13 | LEDA | LED Power:anode | |
| 14 | LEDK | LED Power:cathode | |
| 15 | NC | DUMMY | |
| 16 | TE | TE | |
| 17 | VCC | 2.8V | Power setting |
| 18 | GND | Ground pin for analog circuits | |
| 19 | GND | Ground pin for analog circuits | |
| 20 | NC | NC | |
| 21 | NC | NC | |
| 22 | GND | Ground pin for analog circuits | |
| 23 | NC | NC | |
| 24 | NC | NC |
|
|
