Place of Origin:
Shenzhen,China
Brand Name:
RGH
Certification:
ISO9001/ISO14001
Model Number:
RT169QV003A
Document:
| NO. | Symbol | Leve | Function |
| 1 | LEDA | LED,anode. | |
| 2 | LEDK | LED,cathode. | |
| 3-4 | NC | NC | |
| 5 | NC | NC | |
| 6 | VCC | 2.8V(typ) | Power supply. |
| 7-14 | DB7-DB0 | data bus | |
| 15 | RD | -Read enable in 8080 MCU parallel interface. | |
| 16 | WR | -Write enable in MCU parallel interface. | |
| 17 | RS | -Display data/command selection pin in parallel interface. | |
| 18 | CS | -Chip selection pin | |
| 19 | TE | -Tearing effect signal is used to synchronize MCU to frame memory | |
| 20 | RESET | -This signal will reset the device and it must be applied to properly | |
