Place of Origin:
Shenzhen,China
Brand Name:
RGH
Certification:
ISO9001/ISO14001
Model Number:
RT43WH029B
Document:
| NO. | Symbol | Level | Function |
| 1 | GND | Ground. | |
| 2 | VCC | Power supply. | |
| 3-10 | B0-B7 | Data Bus.Serial 8-bit data input selection. | |
| 11-18 | G0-G7 | Data Bus.Serial 8-bit data input selection. | |
| 19-26 | R0-R7 | Data Bus.Serial 8-bit data input selection. | |
| 27 | GND | Ground. | |
| 28 | CLK | Sample clock. | |
| 29 | HS | Horizontal synchronizingsignal. | |
| 30 | VS | Vertical synchronizing signal. | |
| 31 | DEN | Data Enable. | |
| 32 | DISP | DISP | |
| 33 | GND | Ground. | |
| 9A | LEDK | LED,cathode. | |
| 35 | LEDA | LED,anode. | |
| 36 | GND | Ground. | |
| 37-40 | NC | NC |
|
|
FAQ
1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.
2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).
3. Do you support custom logo on the CTP?
A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.
4. How can I place a sample order?
A: Pls send us your inquiry, our sales will contact you soon.
5. What size LCD display can you provide?
A: 0.96 inch to 20 inch TFT LCD display we can provide.
7. What's your MOQ?
A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.
8. What shipping ways do you support?
A: We can consult with it.
