Place of Origin:
Shenzhern,China
Brand Name:
RGH
Certification:
ISO9001/ISO14001
Model Number:
RT20VG001A
Document:
| NO. | Symbol | Level | Function |
| 1 | LEDA | LED power anode | |
| 2 | LEDK | LED power cathode | |
| 3 | GND | Ground | |
| 4 | VCC | Power setting | |
| 5-13 | GND | Ground | |
| 14 | VS | Vertical sync input | |
| 15 | HS | Horizontal sync input | |
| 16 | DCLK | Dot clock signal for RGB. | |
| 17 | DE | DE | |
| 18-22 | B0-B4 | Data bus. | |
| 23-28 | G0-G5 | Data bus. | |
| 29-33 | R0-R4 | Data bus. | |
| 34 | RESET | Reset signal. | |
| 35 | CS | Chip selection. | |
| 36 | SCL | Serial interface clock | |
| 37 | SDA | Serial data input/output bidirectional pin for SPI interface. | |
| 38 | IOVCC | Power setting | |
| 39 | GND | Ground | |
| 40 | I0VCC | Power setting |
| |
FAQ
1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.
2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).
3. Do you support custom logo on the LCM?
A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.
4. How can I place a sample order?
A: Pls send us your inquiry, our sales will contact you soon.
5. What size LCD display can you provide?
A: 0.96 inch to 21.5 inch TFT LCD display we can provide.
7. What's your MOQ?
A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.
8. What shipping ways do you support?
A: We can consult with it.
