Place of Origin:
Shenzhern,China
Brand Name:
RGH
Certification:
ISO9001/ISO14001
Model Number:
RT43WH040A
Document:
| Item | Specification |
|---|---|
|
Size |
4.3inch |
|
Display mode |
Transmissive TFT |
|
Part NO. |
RT43WH040A |
|
Resolution |
480*272 |
|
Outline size |
105.40(H)*67.10(V)*3.05(T) |
|
Active area |
95.04(H)*53.86(V) |
|
View direction |
12:00 |
|
Piexl pitch |
480(RGB)*272 |
|
Interface |
RGB 24BIT |
|
Backlight |
10LEDS |
|
Surface luminance |
500cd/m2 |
|
Logic voltage |
2.5V-3.3V |
|
Operating temperature |
-10℃~60℃ |
|
Storage temperature |
-20℃~70℃ |
| NO. | Symbo | Level | Function |
| 1-2 | GND | Ground. | |
| 3-4 | VDD | Powersupply | |
| 5-12 | R0-R7 | Data Bus.Serial 8-bit data input selection. | |
| 13-20 | G0-G7 | Data Bus.Serial 8-bit data input selection | |
| 21-28 | B0-B7 | Data Bus.Serial 8-bitdata input selection. | |
| 29 | GND | Ground. | |
| 30 | DCLK | Sample clock | |
| 31 | DISP | DISP | |
| 32 | HSYNC | Horizontal synchronizing signal | |
| 33 | VSYNC | Vertical synchronizing signal. | |
| 34 | DEN | Data Enable. | |
| 35 | NC | NC | |
| 36 | GND | Ground. | |
| 37 | YU | YU | |
| 38 | XL | XL | |
| 39 | YD | YD | |
| 40 | XR | XR | |
| 41 | GND | Ground. | |
| 42 | LEDK | LED,cathode. | |
| 43 | LEDA | LED,anode. | |
| 44-45 | NC | NC |
FAQ
1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.
2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).
3. Do you support custom logo on the LCM?
A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.
4. How can I place a sample order?
A: Pls send us your inquiry, our sales will contact you soon.
5. What size LCD display can you provide?
A: 0.96 inch to 21.5 inch TFT LCD display we can provide.
7. What's your MOQ?
A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.
8. What shipping ways do you support?
A: We can consult with it.
