Place of Origin:
Shenzhern,China
Brand Name:
RGH
Certification:
ISO9001/ISO14001
Model Number:
RTP40WV091A
Document:
Video
Video
Video
| Item | Specification |
|---|---|
|
Size |
3.95inch |
|
Display mode |
Transmissive TFT
|
|
Part NO. |
RTP40WV091A
|
|
Resolution |
480*480 |
|
Outline size |
84.40 (H) X84.40(V) X3.67(T) mm
|
|
Active area |
71.86(H) X70.28(V)
|
|
View direction |
ALL o’clock
|
|
Piexl pitch |
480(RGB)X480
|
|
Interface |
MIPI |
|
Backlight |
8LEDS |
|
Surface luminance |
400cd/m2 |
|
Logic voltage |
2.5V-3.3V |
|
Operating temperature |
-20℃~70℃
|
|
Storage temperature |
-30℃~80℃
|
| NO | Symbol | Leve | Function | |
| 1 | GND | Ground | ||
| 2 | D0N | MIPI DSI differential data pair. | ||
| 3 | D0P | MIPI DSI differential data pair | ||
| 4 | GND | Ground | ||
| 5 | CLKN | MIPI DSI differential clock pair. | ||
| 6 | CLKP | MIPI DSI differential clock pair. | ||
| 7 | GND | Ground | ||
| 8 | D1N | MIPI DSI differential data pair. | ||
| 9 | D1P | MIPI DSI differential data pair | ||
| 10-11 | GND | Ground | ||
| 12 | RESET | RESET.PIN | ||
| 13 | TE | TE-PIN | ||
| 14 | NC | NC | ||
| 15 | GND | Ground | ||
| 16 | NC | NC | ||
| 17 | VDD | Power setting | ||
| 18 | IOVCC | Power setting | ||
| 19 | LEDA | LED anode | ||
| 20 | LEDK | LED cathode | ||
|
|
