Place of Origin:
Shenzhern,China
Brand Name:
RGH
Certification:
ISO9001/ISO14001
Model Number:
RTP31WV012A
Document:
Video
Video
Video
480x800 IPS LCD Capacitive Touchscreen TFT Monitor Display 3.1 Inch ODM
Product Specification
| Screen Size | 3.1 inch |
| Resolution | 480(RGB)X 800 |
| Panel Type | IPS |
| Viewing Angle | ALL o’clock |
| Interface | MIPI |
| Brightness | 500cd/m² |
| Driving IC | ST7701S |
| Contrast Ratio | 1000:1 |
About this item
This 3.1-inch IPS TFT LCD display offers high clarity and vibrant colors in a compact form factor, making it ideal for small, portable devices that require a high-quality display. With a resolution of 480 (RGB) x 800, this display provides sharp images and clear text, delivering a pleasant viewing experience. The IPS panel type ensures wide-angle visibility with consistent color reproduction, and the "ALL O'Clock" viewing angle allows for clear visibility from virtually any direction.
With a brightness level of 500 cd/m², this display performs well even under bright lighting conditions, making it suitable for outdoor or high-ambient light applications. The LED backlight ensures both energy efficiency and a long lifespan, while the high contrast ratio of 1000:1 enhances image quality by providing deeper blacks and brighter whites.
The 30ms response time ensures smooth and quick transitions, ideal for dynamic content such as animations or fast-moving graphics. The MIPI interface allows for seamless integration into various embedded systems, while the inclusion of a touchscreen adds interactive capabilities, making this display perfect for user interfaces, handheld devices, or smart gadgets.
With a compact dimension of 48mm (H) x 88.4mm (V) x 2.93mm (T) and an active area of 40.32mm (H) x 67.2mm (V), this display fits well into small devices without compromising visual performance. Its operating temperature range of -10℃ to 60℃ and storage range of -20℃ to 70℃ ensures stable performance across a range of environments.
Interface Pin Definition
| NO. | Symbol | Level | Function |
| 1 | GND | Ground | |
| 2 | DCLKP | MIPI DSI differential clockpair. | |
| DCLKN | MIPI DSI differential clock pair. | ||
| 4 | GND | Ground | |
| 5 | D0P | MIPI DSI differential data pair. | |
| 6 | D0N | MIPI DSI differential data pair. | |
| 7 | GND | Ground | |
| D1P | MIPI DSI differential datapair. | ||
| 9 | D1N | MIPI DSI differential data pair. | |
| 10 | GND | Ground | |
| 11-12 | NC | NC | |
| 13 | GND | Ground | |
| 14-15 | NC | NC | |
| 16 | LEDA | LED power anode | |
| 17 | LEDK | LED power cathode | |
| 18 | VDD | Power setting | |
| 19 | IOVCC | Power supply for digital interface | |
| 20-21 | NC | NC | |
| 22-23 | GND | Ground | |
| 24 | TP-INT | TP-INT | |
| 25 | TP-RST | TP-RST | |
| 26 | TP-SDA | TP-SDA | |
| 27 | TP-SCL | TP-SCL | |
| 28 | LCM-RST | RESET.PIN | |
| 29 | DSI-TE | TE-PIN | |
| 30 | ID | ID |
External Dimensions
|
|
FAQ
1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.
2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).
3. Do you support custom logo on the LCM?
A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.
4. How can I place a sample order?
A: Pls send us your inquiry, our sales will contact you soon.
5. What size LCD display can you provide?
A: 0.96 inch to 21.5 inch TFT LCD display we can provide.
7. What's your MOQ?
A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.
8. What shipping ways do you support?
A: We can consult with it.
