Place of Origin:
Shenzhern,China
Brand Name:
RGH
Certification:
ISO9001/ISO14001
Model Number:
RTP085001B
Document:
Video
Video
Video
| NO. | Symbo | Leve | Function |
| 1 | GND | Ground | |
| 2 | LEDK | LED power cathode | |
| 3 | LEDA | LED power anode | |
| 4 | VDD | Power setting | |
| 5 | GND | Ground | |
| 6 | GND | Ground | |
| 7 | D/C | command selecion pin in 4-line serial interface | |
| 8 | Cs | Chip selecion pin | |
| 9 | SCL | This pin is used lo beserial inlerfaceclook | |
| 10 | SDA | SPlinter faceinputloutput pin | |
| 11 | RESET | This signal wil reset the device and it must be applied to properly | |
| 12 | GND | Ground |
FAQ
1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.
2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).
3. Do you support custom logo on the LCM?
A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.
4. How can I place a sample order?
A: Pls send us your inquiry, our sales will contact you soon.
5. What size LCD display can you provide?
A: 0.96 inch to 21.5 inch TFT LCD display we can provide.
7. What's your MOQ?
A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.
8. What shipping ways do you support?
A: We can consult with it.
