Place of Origin:
Shenzhern,China
Brand Name:
RGH
Certification:
ISO9001/ISO14001
Model Number:
RT154029B
Document:
Video
| Item | Specification |
|---|---|
|
Size |
1.54inch |
|
Display mode |
Transmissive TFT
|
|
Part NO. |
RT154029B
|
|
Resolution |
240*240 |
|
Outline size |
31.52 (W) X33.72 (H) X1.95(T)
|
|
Active area |
27.72(W) X27.72 (H)
|
|
View direction |
ALL o’clock
|
|
Piexl pitch |
240X(RGB)X240
|
|
Interface |
RGB |
|
Backlight |
3LEDS |
|
Surface luminance |
500cd/m2 |
|
Logic voltage |
2.5V-3.3V |
|
Operating temperature |
-20℃~70℃
|
|
Storage temperature |
-30℃~80℃
|
| NO. | Symbol | Level | Function |
| 1 | GND | Ground. | |
| 2 | LEDK | LED,cathode. | |
| 3 | LEDA | LED,anode. | |
| 4 | VCC | 2.8V | Power setting |
| 5 | GND | Ground. | |
| 6 | GND | Ground. | |
| 7 | D/C | command selection pin in 4-line serial interface | |
| 8 | Cs | Chip selection pin | |
| 9 | SCL | Thispin is used to be serial interface clock | |
| 10 | SDA | SPI interface input/output pin | |
| 11 | RESET | This signal will reset the device and it must be applied to properly | |
| 12 | GND | Ground. |
|
|
FAQ
1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.
2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).
3. Do you support custom logo on the LCM?
A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.
4. How can I place a sample order?
A: Pls send us your inquiry, our sales will contact you soon.
5. What size LCD display can you provide?
A: 0.96 inch to 21.5 inch TFT LCD display we can provide.
7. What's your MOQ?
A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.
8. What shipping ways do you support?
A: We can consult with it.
