Place of Origin:
Shenzhern,China
Brand Name:
RGH
Certification:
ISO9001/ISO14001
Model Number:
RTP40HD003A
Document:
Video
Video
Video
| Item | Specification |
|---|---|
|
Size: |
4.0inch |
|
Display mode |
Transmissive TFT
|
|
Part NO. |
RTP40HD003A
|
|
Resolution |
640*1280 |
|
Outline size |
51.70(H) X101.75(V) X2.97(T)
|
|
Active area |
45.31(H) X90.88(V)
|
|
View direction |
ALL
|
|
Piexl pitch |
640XRGBX1280
|
|
Interface |
MIPI 4L |
|
Backlight |
10LEDS |
|
Surface luminance |
430cd/m2 |
|
Logic voltage |
2.5V-3.3V |
|
Operating temperature |
-20℃~70℃
|
|
Storage temperature |
30℃~80℃
|
| NO. | Symbol | Level | Function |
| 1 | GND | Ground | |
| 2 | DSIO-D3P | MIPI Data pin Positive | |
| 3 | DSIO-D3N | MIPI Data pin Positive | |
| 4 | GND | Ground | |
| 5 | DSIO-D2P | MIPI Data pin Positive | |
| 6 | DSIO-D2N | MIPI Data pin Positive | |
| 7 | GND | Ground | |
| 8 | DSIO-CKP | Mipi clock signal | |
| 9 | DSIO-CKN | Mipi clock signal | |
| 10 | GND | Ground | |
| 11 | DSIO-D1P | MIPI Data pin Positive | |
| 12 | DSIO-D1N | MIPI Data pin Positive | |
| 13 | GND | Ground | |
| 14 | DSIO-D0P | MIPI Data pin Positive | |
| 15 | DSIO-D0N | MIPI Data pin Positive | |
| 16 | LCM-LEDA | LED power anode | |
| 17 | LCM-LEDK | LED power cathode | |
| 18 | NC | NC | |
| 19 | LCM-AVDD | Power setting | |
| 20 | LCM-AVEE | ||
| 21 | DSI-TE | TE | |
| 22 | LCM-RST | RESET.PIN | |
| 23 | GND | Ground | |
| 24 | V1018 PMU | Power supply for digital interface | |
| 25 | LCD-ID | ID | |
| 26 | CTP2V8 | lPower setting | |
| 27 | SCLO | CTP-SCL | |
| 28 | SDAO | CTP-SDA | |
| 29 | EINT-CTP | CTP/INT | |
| 30 | CTP-RSTB | CTP-RESET |
|
|
FAQ
1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.
2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).
3. Do you support custom logo on the LCM?
A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.
4. How can I place a sample order?
A: Pls send us your inquiry, our sales will contact you soon.
5. What size LCD display can you provide?
A: 0.96 inch to 21.5 inch TFT LCD display we can provide.
7. What's your MOQ?
A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.
8. What shipping ways do you support?
A: We can consult with it.
