Place of Origin:
Shenzhern,China
Brand Name:
RGH
Certification:
ISO9001/ISO14001
Model Number:
RTP40WV063A
Document:
Video
Video
Video
| NO. | Symbol | ||
| 1 | GND | Ground | |
| 2 | LEDK | LED power cathode | |
| 3 | LEDA | LED power anode | |
| 4 | GND | Ground | |
| 5 | D1P | MIPI Data pin Positive | |
| 6 | D1N | MIPI Data pin Positive | |
| 7 | GND | Ground | |
| 8 | D0P | MIPI Data pin Positive | |
| 9 | D0N | MIPI Data pin Positive | |
| 10 | GND | Ground | |
| 11 | CLKP | Mipi clock signal | |
| 12 | CLKN | Mipi clock signal | |
| 13 | GND | Ground | |
| 14 | TE | TE | |
| 15 | RESET | RESET.PIN | |
| 16 | GND | Ground | |
| 17 | NC | NC | |
| 18-19 | IOVCC | 1.8V | Power supply for digital interface |
| 20 | GND | Ground | |
| 21-22 | VCC | 2.8V | Power setting |
| 23 | GND | Ground | |
| 24 | TP-RST | TP-RST | |
| 25 | TP-NT | TP-INT | |
| 26 | TP-SCL | TP-SCL | |
| 27 | TP-SDA | TP-SDA | |
| 28 | GND | Ground | |
| 29 | TP-VCC | TP-VCC | |
| 30 | GND | Ground |
|
|
FAQ
1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.
2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).
3. Do you support custom logo on the LCM?
A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.
4. How can I place a sample order?
A: Pls send us your inquiry, our sales will contact you soon.
5. What size LCD display can you provide?
A: 0.96 inch to 21.5 inch TFT LCD display we can provide.
7. What's your MOQ?
A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.
8. What shipping ways do you support?
A: We can consult with it.
