Originating from OLED display technology—Organic Light-Emitting Diodes—it features self-emissive properties. It uses an extremely thin layer of organic material coated onto a glass substrate. When an electric current passes through, these organic materials emit light.   Working Principle AMOLED is based on organic light-emitting materials. Thousands of tiny light sources that can emit only one of the three colors—red, green, or blue—are arranged in a specific pattern on the screen substrate. When voltage is applied, they emit red, green, or blue light. This voltage control relies on TFT (Thin-Film Transistor) technology. By adjusting the proportions of the three primary colors, various colors can be produced.   Advantages   Wide Color Gamut The color gamut refers to the range of colors a display can reproduce. Industry standards include NTSC, sRGB, and Adobe RGB color gamuts. For example, the iPad Air can display about 96% of the sRGB gamut, while Super AMOLED screens can reach close to 100% NTSC, which surpasses sRGB and is closer to the higher Adobe RGB standard (as shown in diagrams comparing the sRGB triangle). A wide color gamut allows the screen to display richer colors and reproduce more real-world hues. More importantly, it enhances contrast, enabling the display to show shadows closer to true black. In traditional Chinese culture, the five “primary” colors are blue-green (cyan), yellow, red, white, and black, symbolizing orthodoxy and nobility. Thanks to its exceptional color range, AMOLED technology can vividly reproduce these colors. For instance, its rendering of sunlight-like yellow or the life-representing cyan between blue and green is especially impressive.   High Contrast Compared to traditional TFT displays, AMOLED can display deep, solid blacks, while TFT displays appear more dark gray. AMOLED also produces pure white, resulting in clearer and more transparent visuals.   Ultra-thin Design AMOLED displays are thinner than LCD screens. LCDs contain a backlight, color filters, a backlight module, and liquid crystal layers, while AMOLED, being self-emissive, does not require these components. Integrated touch technology also makes AMOLED screens thinner and lighter. The world’s first AMOLED integrated touch display debuted in 2010 and was used in premium smartphones.   Outdoor Readability Reading maps or addresses on your phone under strong sunlight is possible with AMOLED. Outdoor readability is proportional to chroma × brightness, and OLED chroma is about 1.7 times that of LCD. This gives AMOLED displays excellent outdoor readability, allowing colors to remain clear under bright sunlight and providing better viewing angles for outdoor reading.   Lower Power Consumption AMOLED screens consume significantly less power than traditional LCDs because each pixel can be individually controlled without a constant backlight. For example, when browsing white-background websites like Baidu, most pixels emit 100% brightness. But when playing dark-scene videos, pixels emit much less light. LCDs, by contrast, always emit 100% backlight brightness and only control brightness locally by rotating liquid crystal molecules. AMOLED pixels can adjust their own brightness independently, meaning they don’t all have to emit at 100% brightness—this saves energy. Even while playing videos or multimedia content, battery drain is minimal. In emergencies, activating an ultra power-saving mode that reduces pixel use to 10% can extend phone usage up to 24 hours.

            3.2インチTFTディスプレイモジュールは、幅広い用途に対応できるよう設計されており、汎用性と信頼性を両立しています。240×RGB×400の解像度と262K色を備え、鮮やかなビジュアルと正確な色再現を実現します。12時の方向からの視認性を最適化し、450 cd/m²の輝度レベルを提供することで、さまざまな照明条件下での視認性を確保しています。 48.40(H) × 81.50(V) × 2.77(T) mmのコンパクトなフォームファクタと、41.76(H) × 69.60(V) mmのアクティブエリアにより、ハンドヘルドシステムや組み込みシステムに最適です。ILI9327ドライバICを搭載し、MCUインターフェースを採用することで、応答性の高いパフォーマンスと簡単な統合をサポートします。動作温度範囲は-20℃～70℃、保管温度範囲は-30℃～80℃で、過酷な環境下でも信頼性の高い性能を発揮するように設計されています。特定のアプリケーション要件に合わせてカスタマイズオプションも利用可能です。

  トランスフレクティブスクリーンは、トランスフレクティブディスプレイまたは半透過/半反射スクリーンとも呼ばれ、反射特性と透過特性の両方を組み合わせたディスプレイ技術です。従来の反射板の代わりに鏡のような反射フィルムを使用しており、スクリーンの前面で周囲光を反射させながら、背面は透明性を維持してバックライトを透過させます。このタイプのスクリーンは、航空機の計器、自動車デバイス、屋外ポータブル電子機器、ハイエンドスマートフォンなどで広く使用されています。   スクリーン表面は、透過光と反射光がそれぞれ50％を占めるようにコーティングされています。明るい環境では反射によって視認性が向上し、暗い環境ではバックライトが照明を提供します。これにより、周囲の照明条件に基づいて適応的なディスプレイ性能が可能になります。   トランスフレクティブスクリーンの秘密は、その半反射フィルムにあります。これは、特定の建物、一部のサングラス、または自動車のウィンドウティントに使用されているガラスに似ています。前面は鏡のように機能し、太陽光を反射して明るい屋外条件下でも読みやすいディスプレイを提供します。一方、背面は透けており、スクリーンのバックライトを透過させます。 トランスフレクティブディスプレイでは、反射型スクリーンの背面にある従来の反射板は、鏡のような反射フィルムに置き換えられます。      このフィルムは前面からは鏡のように見えますが、背面からは透明で、本質的には光を反射および透過するガラスです。完全に透過型のバックライトと組み合わせることで、トランスフレクティブスクリーンは反射型と透過型ディスプレイ技術のハイブリッドになります。   半反射半透過スクリーンの特徴は、バックライトの明るさが屋外環境に自動的に適応することです。屋外の太陽光が強いほど、反射フィルムからの反射バックライト（太陽光）も強くなります。最も強い屋外光強度でさえ問題ありません。周囲光が強いほど、反射バックライトも強くなります。屋外では、追加のバックライト照明装置を完全に必要としないため、完全に透明なスクリーンと比較して大幅な省電力になり、表示効果もはるかに優れています。

  静電容量方式タッチスクリーンの構造は、主にガラススクリーンにコーティングされた透明導電膜層と、その上に保護ガラス層で覆われています。この二重ガラス設計は、導電層とセンサーを徹底的に保護します。   さらに、追加のタッチスクリーンの四辺に沿って細い電極がコーティングされており、導電性材料内に低電圧AC電界を生成します。ユーザーが画面に触れると、人体の電界により、ユーザーの指と導電層の間に結合容量が形成されます。電極から生成された電流はタッチポイントに向かって流れ、その強度は指と各電極間の距離に比例します。画面背面のコントローラーは、電流の比率と強度を計算して、タッチ位置を正確に特定します。静電容量方式タッチスクリーンの二重ガラス設計は、導体とセンサーを保護するだけでなく、外部環境要因からも画面を効果的にシールドします。画面が汚れ、ほこり、またはグリースで汚染されていても、タッチ位置を正確に検出できます。    静電容量方式タッチスクリーンは、4線式抵抗膜方式スクリーンよりも優れた光透過率と鮮明さを提供しますが、表面弾性波方式や5線式抵抗膜方式スクリーンほどではありません。ただし、静電容量方式スクリーンは、激しいグレアに悩まされます。静電容量技術で使用される4層複合設計は、異なる光波長間で不均一な透過率をもたらし、色の歪みを引き起こします。層間の反射も、画像のぼやけや文字のぼやけにつながります。    基本的に、静電容量方式スクリーンは、人体をコンデンサの1つの電極として扱います。導体がITO作業面に十分近づいて十分な静電容量を生成すると、結果として生じる電流が画面の誤動作を引き起こす可能性があります。静電容量は距離に反比例しますが、接触面積に正比例し、媒体の誘電率にも依存します。したがって、手のひらや手持ちの金属物体など、大きな導電性表面が画面の近くにあると、直接接触していなくても誤ったタッチを引き起こす可能性があります。特に湿度の高い条件下ではそうです。たとえば、モニターに手を置いたり、手のひらを7cm以内に置いたり、体を画面から15cm以内に置いたりするだけで、誤った入力をトリガーする可能性があります。    静電容量方式スクリーンのもう1つの欠点は、手袋をはめた手や非導電性の物体で触れても、より多くの絶縁材が存在するため、反応しないことです。ただし、静電容量方式タッチスクリーンの最も重要な問題はドリフトです。環境温度、湿度、または電界の変化は、位置ドリフトを引き起こし、不正確なタッチにつながる可能性があります。たとえば、モニターの電源を入れた後、ユーザーの体が画面に近づいたとき、または近くに大きな物体が移動したときにもドリフトが発生する可能性があります。誰かが使用中に画面の周りに集まると、ドリフトが発生することもあります。    このドリフトの根本原因は、固有の技術的欠陥です。環境ポテンシャル面（ユーザーの体を含む）が指よりも画面から遠くても、その大きな面積はタッチ位置検出に大きく影響します。さらに、多くの理論的に線形な関係は実際には非線形です。たとえば、体重や指の水分レベルが異なるユーザーは、さまざまな量の電流を吸収し、総電流変化と個々の電極電流変化の関係は非線形です。静電容量方式スクリーンは、固定原点のないカスタムの四隅座標系を使用します。ドリフトが発生すると、コントローラーはそれを検出または修正できません。 四隅でのアナログ-デジタル変換後、4つの電流値に基づいて直交座標系でX座標とY座標を計算することは複雑です。固定原点がないため、静電容量方式スクリーンのドリフトは累積的であり、現場での頻繁な再キャリブレーションが必要です。 静電容量方式スクリーンの外側のシリカガラス層は耐傷性に優れていますが、爪や硬い物体からの衝撃に対して脆弱です。小さなチップが内部のITO層を損傷する可能性があります。内部のITO層が使用中、設置中、または輸送中に損傷した場合、静電容量方式スクリーンは正常に機能しなくなります。

2024年9月19日から21日まで   インドネシアのジャカルタで開催された 展覧会に参加しました ロング・グアン・フイのCEOと副マネージャーと 1人の従業員と2人のサプライヤーが一緒でした
